CTP plateHC’s CTP plate can reach 100000 impressions after baking. It can meet various commercial printing, news paper and packaging printing needs. Different specifications, inquire now!
|
What is CTP printing
CTP is a digital printing plate imaging process that goes directly from computer to printing plate. In terms of materials, it eliminates the need for photosensitive film and its washing chemicals; in terms of technology, it eliminates the need for film exposure, washing, plate repair, and plate making; in terms of equipment, it eliminates the need for darkrooms and film exposure and washing equipment; in terms of benefits, it reduces costs, saves time and space; in terms of quality, the image transfer quality is significantly improved, and environmental pollution is reduced. We also have double layer thermal CTP plate.
Plate CTP specification
Product type | Single-layer thermal CTP plate |
Application | High grade commercial and newspaper printing |
Plate thickness | 0.15mm, 0.20mm, 0.25mm, 0.30mm, 0.40mm |
Max width | 1350mm |
Spectral sensitivity | 830nm |
Exposure energy | 110~130mj/Cm2 |
Developing temperature | 22-28℃ |
Resolution | 1~99% at 200lpi |
Developing time | 25-35 sec |
Safety-light | 2 hours under white light |
Run length | Unbaked: 50000-100000 impressions; Baked: more than 100000 impressions. |
Shelf time | 18 months |
Transportation Package | Export standard,seaworthy package |
Specification | 0.15mm100PCS/box;0.25mm50PCS/box;0.30mm50PCS/box; 0.40mm30PCX/box;customized. |
